Our Tooling Capabilities
Comprehensive fixture and tooling solutions for manufacturing excellence
Assembly Jigs
Custom fixtures to speed manual assembly.
Ergonomic jig designs reduce operator fatigue and improve throughput with intuitive part placement and secure clamping.
- Ergonomic operator positioning
- Quick-change components
- Integrated part verification
Inspection Fixtures
Reliable fixturing for QC and CMM inspection.
Designed to integrate with common inspection workflows and reduce false rejects with precise part location and stability.
- CMM-compatible designs
- Repeatable part positioning
- Calibration reference points
Pilot Tooling
Small-run tooling for validation before full investment.
Pilot tooling for process validation and early QA before mass production with scalable designs.
- Low-volume production validation
- Process parameter optimization
- Scalable to high-volume tooling
Measurable Success Outcomes
Tangible results from our custom tooling solutions
- Reduced defects through poka-yoke fixture design
- Shorter cycle times and improved operator ergonomics
- Lower tooling maintenance costs via robust material selection
- Increased production capacity with optimized workflows
- Enhanced part quality consistency across batches
Benefits in Practice
How our tooling solutions deliver real manufacturing advantages
Lower Defects
Fixtures designed to prevent incorrect assembly and reduce rework with error-proofing features.
Faster Cycle
Optimized operator flows and robust clamp designs speed up production with intuitive operation.
Maintainability
Modular fixture design for easier maintenance and replacement parts with standard components.
Tooling Case Study
Real-world results from our custom tooling implementations
Assembly Fixture — Reduced Defects
Implemented jigs that cut cycle time by 18% and reduced operator errors significantly through poka-yoke design principles.
Inspection Fixture — Improved Accuracy
Custom CMM fixture reduced measurement variation by 32% and cut inspection time by 25% with repeatable positioning.
Start Your Tooling Project
Get custom fixtures and tooling designed for your specific manufacturing needs
Contact Our Tooling Team
